X，Y axis adopt square rail and ball screw transmission to make machine more stable,higher accuracy.
Stable and full equipped design concept,equipped with advanced industrial cooling system,with anhydrous alarm automatic protection system,improve the stability and safety of continuous work.
Full-equipped dust,anti-pollution exhaust system,more attention to environmental protection.
Applications
‖Advertising Industry:Acrylic,double color board ＆ other advertising material engraving ＆ cutting.
‖Leather Industry:Engraving ＆ through-carving on leather ＆ cloth.
‖ Craft Industry:Engrave and cut on paper,wooden material,bamboo,leather,seashell ＆ ivory material.
‖Model Industry:Cutting for architectural model,Aviation and navigation model,wooden toy.
‖Packaging Industry:Engrave ＆ cut on rubber,composite board ＆ Laser die board.
‖Engrave ＆ cut in decoration industry ＆ electronic appliance industry materials.
Parameters
| 产品型号 Laser model |
MK-1318 MK-1325 MK-1625 |
| 激光类型Laser Type |
co2封闭式玻璃管激光器波10.6μm，Glass Sealed-off co2 laser tube,wavelength 10.6μm |
| 激光管功率Laser Power |
40W 60W 80W 100W 150W |
| 冷却方式Laser Tube Cooling |
水冷 Purified Recycling Water Cooling |
| 能量调节Laser Output Control |
0-100％无段控制，软件内部0-100％可调 Non Section Control,Software inner adjustment from0-100％ |
| 控制及驱动Control System and Driver |
DSP控制 步进电机驱动DSP Control,High Subdivision Driver,Stepper Motor |
| 雕刻速度Engraving Speed |
0-1200mm/s |
| 切割速度Cutting Speed |
0-600mm/s |
| 工作电压Working Voltage |
AC220v/110V±10％ 50HZ/60HZ |
| 定位精度Position Accuracy |
≤±0.01mm |
| 最小成型字Minimum Letter Size |
汉子1.5mm 英文字母1mm Chinese:1.5mm English:1mm |
| 整机功率Machine Power |
≤1000W |
| 加工幅面Working Area |
1300mm×1800mm 1300mm×2500mm 1600mm×2500mm |
| 工作台升降Rise and Fall Height |
手动调整（adjusted manually）100mm |
| 工作环境working Environment |
温度：0-45℃ 湿度：5％-95％ （无凝水）Temperature:0-45℃ Humidity:5％-95％ |
| 软件支持格式Supported Format |
PLT、DST 、DXF、BMP 、AI可支持（Support）AutoCAD、CorelDraw直接输出（、output directly） |
